2 x 9/16-18 (adapters) Male lnlets : These are located at the top in the picture and they have the red caps on them! These are screw into the block and may be removed to use 3/8-24 female ports
1 x 3/8-24 Female outlet
Made from a solid brass block and then electro-plated for a protective finish!
knob is made out of high quality aluminum and is anodized black! Also ribbed to work with or without gloves on easy
Inlet adapters can be removed to expose 3/8-24 female ports
Light weight design as this little block comes in at: 534g / 1.17 Pounds
This block allows a diver to change between two separate air tanks without having to remove Their full face mask and the knob can turns a full 180 degrees
This is set up for a left side application
This part is NITROX READY right out of the packaging!
Our transfill whip has 300 bar DIN connectors on each end so you can fill to any din system
Our Gauge is oil filled to ensure accuracy
Large 2" inch gauge face makes reading easy and simple in either PSI or BAR!
Gauge has both PSI and BAR Scale in 100 PSI increments
Our high pressure hose is roughly 60" inches long and is made out of a tough kevlar inner braided material with a poylmer outer shealth
Rotating bleed valve knod located just under the gauge allows you to maintain a high accuracy and better control when filling your cylinders
This is our larger bore transfill hose in diameter which will allow you to move your air / mix faster from one cylinder to another!
You can use our whip in multiple ways such as to equalize cylinders, transfill from "doubles banks" or filling smaller rebreather bottles
***NOTICE: Our whips are sent with the pressure gauge not conntacted to protect from damage during shipping! You just remove the one port plug and screw in the gauge.. DO NOT USE teflon tape or anything on the threads just screw it in!
Our transfill whip has 300 bar DIN connectors on each end
Our new pony bottle gauge is smaller and simpler to handle but still has an high accuracy
Our pony bottle gauge face makes reading easy and simple in either PSI or BAR! The color coding makes looking at where you are with your transfill simple!!
Gauge has both PSI and BAR Scale in 100 PSI increments with a color fill bar graph
Our high pressure Large Bore hose is roughly 60" inches long
Rotating bleed knob located near the pony gauge allows for easy control of your fill
You can use our whip in multiple ways such as to equalize cylinders, transfill from "doubles banks" or filling smaller rebreather bottles
NOTE: You are purchasing a large bore hose which moves the air much faster then our braided hose transfill whips
Our transfill whip has 300 bar DIN connectors on each end
Each Gauge is oil filled to ensure accuracy and durablility
Large gauge face makes reading easy and simple in either PSI or BAR!
Gauge has both PSI and BAR Scale in 100 PSI increments
Our high pressure hose is roughly 60" inches long
Bleed valve at the bottom of the SPG guage area allows you to maintain a high accuracy and better control when using
You can use our whip in multiple ways such as to equalize cylinders, transfill from "doubles banks" or filling smaller rebreather bottles
Note: This whip moves your gas slower than our standard whip so please keep this in mind when purchasing. Uses a smaller bore hose which allows gas to move from 1 cylinder to another just at a slower rate!
***NOTICE: Our whips are sent with the pressure gauge not conntacted to protect from damage during shipping! You just remove the one port plug and screw in the gauge.. DO NOT USE teflon tape or anything on the threads just screw it in!
2 x 9/16-18 (adapters) Male lnlets : These are located at the top in the picture and they have the red caps on them! These are screw into the block and may be removed to use 3/8-24 female ports
1 x 3/8-24 Female outlet
Made from a solid brass block and then electro-plated for a protective finish!
knob is made out of high quality aluminum and is anodized black! Also ribbed to work with or without gloves on easy
Inlet adapters can be removed to expose 3/8-24 female ports
Light weight design as this little block come in at: 534g / 1.17 Pounds
This block allows a diver to change between two separate air tanks without having to remove Their full face mask and the knob can turns a full 180 degrees
This is set up for a right side application
This part is NITROX READY right out of the packaging!
This fitting works with Apeks/Aqualung/SeaQuest and Zeagle Bc connection
Use for a quick connection on the hose end or your regulator make threaded end!
Multi use connection
Size: Female thread size 9/16-18
Rebreather Info
Use our LHA Quick Disconnect male to work with a 9/16"-18 Female fitting such as our AB-04 or AH-202 fittings located in the rebreather hardware section!
Connections for BOVs or OC 2nd stage regulators
This connector is NOT compatible with CEJN fittings
Our kit includes one locking quick disconnect AB-04 connector and we marry that with our LH-A regulator side connection 9/16 fitting but you MUST select which fitting you wish with your kit! Choose down below!!
NOTE: You can now select either fitting from our drop down box below to complete your set-up
Detailed Information
Quick disconnect for BOV or second stage regulator
Also check out our newest adapter our Deluxe LH-A adapter! Its costs very little to upgrade to our best adapter yet!
Female 9/16 thread on our LH-A connector NOTE: The nipple to screw on the BOV or second stage
Male 9/16 thread on locking AB-04 Quick Disconnect locking slider to screw on standard low pressure regulator hoses
Our AB-04 quick disconnet locking slider is sealed shut when disconnected for added safety. We use a locking ring mechanism protecting against accidental disconnection during a dive!
BOV Quick Disconnect kit with non-locking connector system
Our kit includes one non-locking quick disconnect AH-202 connector and we marry that with our LH-A regulator side connection 9/16 fitting.. You MUST select from our drop down box below which fitting you wish with your kit! The standard fitting is the LH-A with our Newest fitting our Deluxe LH-A!! Check out this one for the small upgrade costs
Detailed Information
Quick disconnect for BOV or second stage regulator
Female 9/16 thread on our LH-A connector NOTE: The nipple to screw on the BOV or second stage
Male 9/16 thread on non-locking AH-202 Quick Disconnect non-locking slider to screw on standard low pressure regulator hoses
Our AH-202 quick disconnet non-locking slider is sealed shut when disconnected for added safety!
This is for the rebreather diver who prefers not to use a locking ring quick disconnect connector!
Our din plug is made from a solid brass block and when finished we have an electro-plated finish put on it to make it durable and looks great
This new plug has a special pressure release button in the center of the plug! When gas gets trapped inside instead of taking a wrench you just pressure the button and the gas that is trapped releases. This makes removing the plug a snap just make sure you have turned off your main valve
No more losing your expensive gas with these plugs in
If you already own or had a transfill whip but your hose went bad no worries you can purchase just the hose to use with your fitting!
This is are larger bore hose which transfer a little more air then our braided counter part
You can add your din or yoke fitting with this hose!
NOTE: Make sure you use teflon tape on the threaded ends when you screw your fitting onto the hose so it does not leak
Piranha's Price: $89.99
Transfill Whips and Hoses
Transfer air between cylinders at home rather than paying for a partial fill. We stock DIN cylinder transfill hoses in braided and rubber, 60 inch whips with a large 2 inch gauge and without, large bore versions for quicker transfers, and hose-only options for divers who already have a gauge.
