Please cntact us for availability first before purchasing since these are running around 12 weeks! Email us at piranhadivemfg@yahoo.com to check if you wish but these are taking longer then notmail!
You are purchasing one Analytical sensor
These cells are the heavy duty version of the MD cells with a slightly higher milli-volt output on them
You are purchasing a PSR-11-39-MHD 3 sensor pack
This cell replaces the following cell: Teledyne R-22, Maxtec Max 12 / Max-305, IT Gambert D04
Please cntact us for availability first before purchasing since these are running around 12 weeks! Email us at piranhadivemfg@yahoo.com to check if you wish but these are taking longer then notmail!
You are purchasing one Analytical sensor
You are purchasing a PSR-11-39-MD 3 sensor pack!
This cell replaces the following cell: Teledyne R-22, Maxtec Max 12 / Max-305, IT Gambert D04
You are purchasing one Analytical sensor that fits the ALL Meg rebreather's! This is their latest cell which has been redsigned to fit into the space of the newer model but still work with their older models!!
You are purchasing a Narked at 90 cell which is made by Vendergraph in Germany
Works on any Meg Rebreather unit
NOTE: Looking for a 3 pack go to our other tab 3 pack cells and save $$$
One of the improvements of these cells is the temperature compensation specification. At present all different manufacturers sensors will react differently to temperature. Inferior temperature compensation circuits will cause other cells to react differently and be voted out! Therefore it is our recommendation NOT to MIX different manufacturers sensors!
You will also SAVE $$$ when purchasing our 3 pack of sensor cells!
Specs:
OEM model number NaNM01 Oxygen Sensor Output 9 - 13 mV
Output connector MOLEX Input
Threaded M16 x 1mm Input
O ring Yes
Range 0 - 100%
Oxygen Pressure range 600 to 2500 mbar
Linearity error 0.1 to 1.0 bar < 3% relative 0.1 to 2.5 bar < 5% relative
Warm up time < 30 minutes after sensor installed Zero offset voltage
< 0.5% oxygen reading in 100% nitrogen @ 25?C after 36 seconds Cross interference
<0.5% vol. O2 response to 5% CO2 balance N2
Response time < 5 s for 90% of final value
Operating humidity 0 - 99% R.H. (non-condensing). Influence of humidity - 0.03% relative per % R.H. at 25 ?C
Influence of mechanical shock < 1% after fall from 1m Operating temperature range 0 - 50 ?C
Storage temperature -20 to +50 ?C
Recommended storage temperature +5 to +15 ?C
Temperature compensation Integrated NTC network Temperature compensation error 0 ?C to 50 ?C, 5% relative error
Nominal sensor life 500,000 % oxygen hours Long term output drift < 1% vol oxygen per month, typically < -15% over sensor lifetime.
Shelf life 24 months
Warranty period 12 months from date of sales invoice
Sensor is a K-22D Oxygen Sensor K22D SMB... Uses the female coaxial connector
One of the improvements of these cells is the temperature compensation specification. At present all different manufacturers sensors will react differently to temperature. Inferior temperature compensation circuits will cause other cells to react differently and be voted out! Therefore it is our recommendation NOT to MIX different manufacturers sensors!
You will also SAVE $$$ when purchasing our 3 pack of sensor cells!
Specs:
OEM model number NaNM01 Oxygen Sensor Output 9 - 13 mV
Threaded M16 x 1mm Input
O ring Yes
Range 0 - 100%
Oxygen Pressure range 600 to 2500 mbar
Linearity error 0.1 to 1.0 bar < 3% relative 0.1 to 2.5 bar < 5% relative
Warm up time < 30 minutes after sensor installed Zero offset voltage
< 0.5% oxygen reading in 100% nitrogen @ 25?C after 36 seconds Cross interference
<0.5% vol. O2 response to 5% CO2 balance N2
Response time < 5 s for 90% of final value
Operating humidity 0 - 99% R.H. (non-condensing). Influence of humidity - 0.03% relative per % R.H. at 25 ?C
Influence of mechanical shock < 1% after fall from 1m Operating temperature range 0 - 50 ?C
Storage temperature -20 to +50 ?C
Recommended storage temperature +5 to +15 ?C
Temperature compensation Integrated NTC network Temperature compensation error 0 ?C to 50 ?C, 5% relative error
Nominal sensor life 500,000 % oxygen hours Long term output drift < 1% vol oxygen per month, typically < -15% over sensor lifetime.
Shelf life 24 months
Warranty period 12 months from date of sales invoice
Piranha's Price: $340.99
Rebreather 3 Pack Sensor Kits
Change all three cells at once so they age together. We stock Analytical PSR-11-39-MD 3 packs and the heavy duty MHD version, 305 Maxtec 3 packs, Titan rebreather 3 sensor sets, and the Meg sensor cell from Narked at 90 that fits all Meg models.
